StressCheck Tutorial: Computation of Cross Section Centroid
Abstract: Using intrinsic functions SPCTRX, SPCTRY and SPCTRZ to compute the global X, Y, Z locations of a cross section centroid. The locations are computed through the application of a “dummy” traction (with X=SPCTRX/SPAREA, Y=SPCTRY/SPAREA and Z=SPCTRZ/SPAREA) to the surface or surfaces representing the cross section, and then performing a load check to return the X, Y, Z locations of the centroid.
