StressCheck Tutorial: Detecting and Correcting Multi-Body Contact Penetration
Abstract: Using the deformed shape to check for penetration (shared space) between parts after a multi-body contact analysis. Adjustment of the contact spring stiffness (Kc) based on penetration and contact zone resultant checks. Determination of the optimal Kc for a given multi-body contact analysis.
