StressCheck Tutorial: Surface Loads Browser for Checking Load Assignments
Abstract: The Surface Loads Browser, enabled from Tools > Surface Loads…, lets the user query a surface for load assignment(s). If a load assignment has been made to the selected surface, a list of load records associated with that surface will be returned. If a load record in the list is double-clicked, the load record will appear in the Model Input window Load tab for editing.
