StressCheck Demo: Bonded Composite Repair Patch for Cracked Hole
Abstract: Modeling and linear analysis of an adhesively-bonded composite doubler repair patch over a hole with an elliptical part-thru crack. The goal is to reduce the SIF’s at the crack front and extend the life of the plate.
